Set the weighted-sum multi-objective method

Configure a Problem object to be solved with a weighted-sum multi-objective method.

In the weighted-sum method, several registered atomic objectives are combined into a single scalar objective using a weighted linear combination. This function stores that configuration in x$data$method so that it can be used later by solve.

Usage

set_method_weighted_sum(
  x,
  aliases,
  runs = NULL,
  weights = NULL,
  normalize_weights = TRUE,
  objective_scaling = FALSE,
  control = NULL
)

Arguments

x: A Problem object.
aliases: Character vector of objective aliases to combine. Each alias must correspond to a previously registered atomic objective.
runs: A run design created with run_grid or run_manual. For weighted-sum methods, automatic grids define weight combinations, while manual runs must contain columns named weight_<alias>.
weights: Deprecated. Numeric vector of weights, with the same length and order as aliases. This argument is kept for backwards compatibility and is internally converted to runs = run_manual(...). New code should use runs instead.
normalize_weights: Logical. If TRUE, normalize the weights in each run to sum to one before solving.
objective_scaling: Logical. If TRUE, request scaling of the participating objectives before weighted aggregation in the solving layer.
control: A control object created with mo_control. It controls how infeasible runs, runs without a solution, and unexpected errors are handled.

Value

The updated Problem object with the weighted-sum method configuration stored in x$data$method.

Details

Use this method when several registered objectives should be combined into a single scalar optimization problem through explicit preference weights.

General idea

Suppose that a set of atomic objectives has already been registered in the problem under aliases $k \in \mathcal{K}$. Let $f_k(x)$ denote the scalar value of objective $k$, and let $w_k$ denote its weight.

The weighted-sum method combines them into a single scalar objective of the form:

$$ \sum_{k \in \mathcal{K}} w_k \, f_k(x). $$

In practice, the exact sign convention used internally depends on the sense of each registered atomic objective, for example whether it is a minimization-type or maximization-type objective. The solving layer is responsible for constructing a solver-ready scalar objective from the stored objective specifications and the requested weights.

Run designs

Weighted-sum runs are specified through the runs argument. This argument must be created with either run_grid or run_manual.

run_grid(n = ...) automatically generates a grid of weight combinations. For two objectives, this is a regular sequence of weights along the line between the two objectives. For three or more objectives, the grid is generated over the weight simplex, where all weights are non-negative and sum to one.

run_manual() allows users to provide explicit weight combinations. In manual weighted-sum runs, each row is one optimization run and columns must be named weight_<alias>. For example, if aliases = c("cost", "benefit"), the manual run table must contain columns weight_cost and weight_benefit.

The older weights argument is deprecated. It is still accepted for backwards compatibility and is internally converted to a one-row run_manual() design.

Atomic objectives requirement

The weighted-sum method can only be used with atomic objectives that have already been registered under aliases. These aliases are typically created by calling objective setters with an alias argument, for example:


x <- x |>
  add_objective_min_cost(alias = "cost") |>
  add_objective_min_fragmentation(alias = "frag")

Internally, each atomic objective is stored in x$data$objectives[[alias]] together with its metadata, such as:

objective_id,
model_type,
sense,
objective_args.

The aliases argument passed to this function selects which of those registered atomic objectives are included in the weighted combination.

Weight normalization

If normalize_weights = TRUE, the weights in each run are rescaled to sum to one:

$$ \tilde{w}_k = \frac{w_k}{\sum_{j \in \mathcal{K}} w_j}. $$

This normalization does not change the optimizer's solution in a pure weighted-sum formulation as long as all weights are multiplied by the same positive constant, but it can improve interpretability and numerical conditioning.

If normalize_weights = FALSE, each row of weights must already sum to one.

Objective scaling

If objective_scaling = TRUE, the solving layer scales the participating objectives before combining them. The purpose of scaling is to reduce distortions caused by objectives being measured on very different numerical ranges.

Conceptually, if $R_k$ denotes a scale or range associated with objective $k$, then a scaled weighted sum may be interpreted as:

$$ \sum_{k \in \mathcal{K}} w_k \, \frac{f_k(x)}{R_k}. $$

The exact scaling rule is implemented in the solving layer.

Mixed objective senses

Weighted sums are straightforward when all participating objectives have the same optimization sense. When minimization and maximization objectives are mixed, the solving layer standardizes them internally before building the scalar objective.

Users should provide non-negative weights according to the original meaning of each objective. For example, a positive weight on a maximization objective means that higher values of that objective are preferred.

Failure handling

The control argument controls how failed runs are handled. It must be created with mo_control.

Weighted-sum runs do not normally introduce additional constraints, so they should not usually create infeasible subproblems by themselves. However, runs may still fail if the underlying model is infeasible, the solver stops before finding a feasible solution, or a numerical/modeling issue occurs. The control argument determines whether such failures stop the whole solve or are retained in the returned SolutionSet with missing objective values.

Theoretical limitation

The weighted-sum method typically recovers only supported efficient solutions, that is, solutions lying on the convex hull of the Pareto front in objective space. In non-convex multi-objective problems, especially mixed integer problems, some efficient solutions cannot be obtained by any weighted combination. In such cases, methods such as set_method_epsilon_constraint or set_method_augmecon may be preferable.

Stored configuration

This function stores the method definition in x$data$method with:

name = "weighted",
type = "weighted",
aliases,
runs,
normalize_weights,
objective_scaling,
control.

The actual scalarization is performed later by solve.

Examples

# Small toy problem
pu_tbl <- data.frame(
  id = 1:4,
  cost = c(1, 2, 3, 4)
)

feat_tbl <- data.frame(
  id = 1:2,
  name = c("feature_1", "feature_2")
)

dist_feat_tbl <- data.frame(
  pu = c(1, 1, 2, 3, 4),
  feature = c(1, 2, 2, 1, 2),
  amount = c(5, 2, 3, 4, 1)
)

actions_df <- data.frame(
  id = c("conservation", "restoration"),
  name = c("conservation", "restoration")
)

effects_df <- data.frame(
  pu = c(1, 2, 3, 4, 1, 2, 3, 4),
  action = c("conservation", "conservation", "conservation", "conservation",
             "restoration", "restoration", "restoration", "restoration"),
  feature = c(1, 1, 1, 1, 2, 2, 2, 2),
  benefit = c(2, 1, 0, 1, 3, 0, 1, 2),
  loss = c(0, 0, 1, 0, 0, 1, 0, 0)
)

x <- create_problem(
  pu = pu_tbl,
  features = feat_tbl,
  dist_features = dist_feat_tbl,
  cost = "cost"
) |>
  add_actions(actions_df, cost = c(conservation = 1, restoration = 2)) |>
  add_effects(effects_df) |>
  add_objective_min_cost(alias = "cost") |>
  add_objective_max_benefit(alias = "benefit")

# Automatic weight grid
x1 <- set_method_weighted_sum(
  x,
  aliases = c("cost", "benefit"),
  runs = run_grid(n = 5, include_extremes = TRUE),
  objective_scaling = TRUE
)

x1$data$method
#> $name
#> [1] "weighted"
#>
#> $type
#> [1] "weighted"
#>
#> $aliases
#> [1] "cost"    "benefit"
#>
#> $runs
#> $type
#> [1] "grid"
#>
#> $n
#> [1] 5
#>
#> $include_extremes
#> [1] TRUE
#>
#> attr(,"class")
#> [1] "RunGrid"   "RunDesign"
#>
#> $normalize_weights
#> [1] TRUE
#>
#> $objective_scaling
#> [1] TRUE
#>
#> $control
#> $stop_on_infeasible
#> [1] FALSE
#>
#> $stop_on_no_solution
#> [1] FALSE
#>
#> $stop_on_error
#> [1] TRUE
#>
#> $slack_upper_bound
#> [1] 1e+06
#>
#> attr(,"class")
#> [1] "MOControl" "list"
#>
#> $stop_on_infeasible
#> [1] FALSE
#>
#> $stop_on_no_solution
#> [1] FALSE
#>
#> $stop_on_error
#> [1] TRUE
#>

# Manual weighted runs
manual_weights <- data.frame(
  weight_cost = c(1.0, 0.75, 0.50, 0.25, 0.0),
  weight_benefit = c(0.0, 0.25, 0.50, 0.75, 1.0)
)

x2 <- set_method_weighted_sum(
  x,
  aliases = c("cost", "benefit"),
  runs = run_manual(manual_weights),
  normalize_weights = FALSE,
  objective_scaling = TRUE
)

x2$data$method
#> $name
#> [1] "weighted"
#>
#> $type
#> [1] "weighted"
#>
#> $aliases
#> [1] "cost"    "benefit"
#>
#> $runs
#> $type
#> [1] "manual"
#>
#> $values
#>   weight_cost weight_benefit
#> 1        1.00           0.00
#> 2        0.75           0.25
#> 3        0.50           0.50
#> 4        0.25           0.75
#> 5        0.00           1.00
#>
#> attr(,"class")
#> [1] "RunManual" "RunDesign"
#>
#> $normalize_weights
#> [1] FALSE
#>
#> $objective_scaling
#> [1] TRUE
#>
#> $control
#> $stop_on_infeasible
#> [1] FALSE
#>
#> $stop_on_no_solution
#> [1] FALSE
#>
#> $stop_on_error
#> [1] TRUE
#>
#> $slack_upper_bound
#> [1] 1e+06
#>
#> attr(,"class")
#> [1] "MOControl" "list"
#>
#> $stop_on_infeasible
#> [1] FALSE
#>
#> $stop_on_no_solution
#> [1] FALSE
#>
#> $stop_on_error
#> [1] TRUE
#>

# Manual runs with automatic weight normalization
manual_weights2 <- data.frame(
  weight_cost = c(2, 1, 1),
  weight_benefit = c(1, 1, 3)
)

x3 <- set_method_weighted_sum(
  x,
  aliases = c("cost", "benefit"),
  runs = run_manual(manual_weights2),
  normalize_weights = TRUE
)

x3$data$method
#> $name
#> [1] "weighted"
#>
#> $type
#> [1] "weighted"
#>
#> $aliases
#> [1] "cost"    "benefit"
#>
#> $runs
#> $type
#> [1] "manual"
#>
#> $values
#>   weight_cost weight_benefit
#> 1           2              1
#> 2           1              1
#> 3           1              3
#>
#> attr(,"class")
#> [1] "RunManual" "RunDesign"
#>
#> $normalize_weights
#> [1] TRUE
#>
#> $objective_scaling
#> [1] FALSE
#>
#> $control
#> $stop_on_infeasible
#> [1] FALSE
#>
#> $stop_on_no_solution
#> [1] FALSE
#>
#> $stop_on_error
#> [1] TRUE
#>
#> $slack_upper_bound
#> [1] 1e+06
#>
#> attr(,"class")
#> [1] "MOControl" "list"
#>
#> $stop_on_infeasible
#> [1] FALSE
#>
#> $stop_on_no_solution
#> [1] FALSE
#>
#> $stop_on_error
#> [1] TRUE
#>

# Backwards-compatible deprecated usage
x4 <- set_method_weighted_sum(
  x,
  aliases = c("cost", "benefit"),
  weights = c(0.4, 0.6),
  normalize_weights = FALSE
)
#> Warning: `weights` is deprecated. Use `runs = run_manual(data.frame(weight_<alias> = ...))` instead.

x4$data$method
#> $name
#> [1] "weighted"
#>
#> $type
#> [1] "weighted"
#>
#> $aliases
#> [1] "cost"    "benefit"
#>
#> $runs
#> $type
#> [1] "manual"
#>
#> $values
#>   run_id weight_cost weight_benefit
#> 1      1         0.4            0.6
#>
#> attr(,"class")
#> [1] "RunManual" "RunDesign"
#>
#> $normalize_weights
#> [1] FALSE
#>
#> $objective_scaling
#> [1] FALSE
#>
#> $control
#> $stop_on_infeasible
#> [1] FALSE
#>
#> $stop_on_no_solution
#> [1] FALSE
#>
#> $stop_on_error
#> [1] TRUE
#>
#> $slack_upper_bound
#> [1] 1e+06
#>
#> attr(,"class")
#> [1] "MOControl" "list"
#>
#> $stop_on_infeasible
#> [1] FALSE
#>
#> $stop_on_no_solution
#> [1] FALSE
#>
#> $stop_on_error
#> [1] TRUE
#>

# Control failure handling
x5 <- set_method_weighted_sum(
  x,
  aliases = c("cost", "benefit"),
  runs = run_grid(n = 5),
  control = mo_control(
    stop_on_infeasible = TRUE,
    stop_on_no_solution = TRUE,
    stop_on_error = TRUE
  )
)

x5$data$method
#> $name
#> [1] "weighted"
#>
#> $type
#> [1] "weighted"
#>
#> $aliases
#> [1] "cost"    "benefit"
#>
#> $runs
#> $type
#> [1] "grid"
#>
#> $n
#> [1] 5
#>
#> $include_extremes
#> [1] TRUE
#>
#> attr(,"class")
#> [1] "RunGrid"   "RunDesign"
#>
#> $normalize_weights
#> [1] TRUE
#>
#> $objective_scaling
#> [1] FALSE
#>
#> $control
#> $stop_on_infeasible
#> [1] TRUE
#>
#> $stop_on_no_solution
#> [1] TRUE
#>
#> $stop_on_error
#> [1] TRUE
#>
#> $slack_upper_bound
#> [1] 1e+06
#>
#> attr(,"class")
#> [1] "MOControl" "list"
#>
#> $stop_on_infeasible
#> [1] TRUE
#>
#> $stop_on_no_solution
#> [1] TRUE
#>
#> $stop_on_error
#> [1] TRUE
#>
